VAN XẢ NƯỚC TỰ ĐỘNG JORC KAPTIV-CS

Mã sản phẩm: KAPTIV-CS

Giá: Liên hệ

Mô tả sản phẩm:

VAN XẢ NƯỚC TỰ ĐỘNG CẢM BIẾN MỨC NƯỚC
HÃNG SẢN XUẤT: JORC
XUẤT XỨ: HÀ LAN
Model: KAPTIV-CS
Mã số: 3403 A3 (230 VAC, 1/2’’, 0-16 bar)
Mã số: 3423 A3 (115 VAC, 1/2’’, 0-16 bar)
Mã số: 3463 A3 (24 VAC, 1/2’’, 0-16 bar)
Mã số: 3483 A3 (24 VDC, 1/2’’, 0-16 bar)

Hỗ trợ trực tuyến

0919 243 248

zalo

Email: sales@congtympt.com

VAN XẢ NƯỚC TỰ ĐỘNG CẢM BIẾN MỨC NƯỚC
HÃNG SẢN XUẤT: JORC
XUẤT XỨ: HÀ LAN
Model: KAPTIV-CS drains with Alarm
Zero air loss condensate drains.
Mã số: 3403 A3 (230 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/O))
Mã số: 3423 A3 (115 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/O))
Mã số: 3463 A3 (24 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/O))
Mã số: 3483 A3 (24 VDC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/O))

Mã số: 3403 A4 (230 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/C))
Mã số: 3423 A4 (115 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/C))
Mã số: 3463 A4 (24 VAC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/C))
Mã số: 3483 A4 (24 VDC, 1/2’’, 0-16 bar, Alarm mode: Normally Open (N/C))
Để biết thêm thông tin chi tiết về sản phẩm: Hình ảnh, kích thước, giá và tồn kho
Vui lòng liên hệ:
Công ty TNHH Máy và Thiết Bị Khí Nén MPT
Hotline/ Zalo: 0919243248
Email: tam.hoang@congtympt.com
Website: www.congtympt.com

KAPTIV-CS
Electronic zero air loss drain

The KAPTIV-CS (Compact Solution) removes all types of condensate from compressed air systems up to 100 m³/min. without the loss of compressed air.

The KAPTIV-CS is cost effective and offers a rapid pay-back period due to a competitive pricing level, low stocking cost, zero air loss and energy saving features.

The compact robust industrial housing, 2/2 way direct acting valve with a large orifice, alarm N/C or N/O and the integrated mesh strainer make the KAPTIV-CS a highly reliable draining solution. The KAPTIV-CS can be applied in oil lubricated as well as oil-free applications.

FEATURES

Robust aluminium housing with three inlet options, offering you installation flexibility.

KAPTIV-CS feature 1

Digital, LED illuminated sight-port/level indicator digitally showing you the condensate level inside the reservoir and enabling you to monitor the KAPTIV-CS's operation, even in poor lit places.

KAPTIV-CS feature 2

Extremely easy to disassemble, offering dissasembly simplicity and time saving during routine maintenance.

KAPTIV-CS feature 3

Capacitive level sensing technology saves air, energy and money.
Competitive compact level sensed draining solution.
Rapid pay-back period due to competitive pricing level and reduced stocking costs.
The KAPTIV-CS can be connected to any alarm device.
Alarm function (N/O or N/C) standard incorporated.
Successful draining of all types of condensate due to large orifice.
Easy installation and visual display of operating status.
Direct acting valve assembly, ensuring reliable discharge operation.

SPECIFICATIONS

MAX. COMPRESSOR CAPACITY	100 m³/min. (3500 CFM)
MAX. DRAINAGE CAPACITY A3/A4 VERSION	665 liters condensate per hour at 16 bar
MIN./MAX. SYSTEM PRESSURE	0 - 16 bar (0 - 230 psi)
MIN./MAX. MEDIUM TEMPERATURE	1 - 50 °C (34 - 122 °F)
MIN./MAX. AMBIENT TEMPERATURE	1 - 50 °C (34 - 122 °F)
SUPPLY VOLTAGE OPTIONS	230VAC / 115VAC / 24VAC / 24VDC
ENCLOSURE PROTECTION RATING	IP65 (NEMA4)
CONNECTOR TYPE (POWER AND ALARM)	DIN 43650-B
INLET CONNECTIONS	1/2″ BSP or NPT, 3 inlet options
INLET HEIGHT	11 cm (top) and 7.5 & 1.5 cm (side)
OUTLET CONNECTION	1/4″ BSP, with brass hose barb adapter
VALVE TYPE	2/2 way, direct acting
VALVE ORIFICE	4 mm
VALVE SEALS	FPM
SERVICEABLE VALVE	Yes
INTEGRATED MESH STRAINER	Yes
HOUSING MATERIAL	Corrosion resistant aluminium, EP coating
TEST FEATURE	Yes
VISUAL ALARM	Yes, LED indication
ALARM FEATURE A3 (N/O)	Normally Open alarm output contact -potential free relay (Normally open contacts, closed when in alarm mode. LED on the drain is OFF in normal operation and ON when in alarm mode)
ALARM FEATURE A4 (N/C)	Normally Closed alarm output contact -potential free relay (Normally closed contacts, open when in alarm mode. LED on the drain is OFF in normal operation and ON when in alarm mode)
