PHAO XẢ NƯỚC TỰ ĐỘNG NUFORS-XF, 3806

NUFORS-XF DRAIN

PNEUMATIC ZERO AIR LOSS DRAINS WITH A 12 MM ORIFICE & THREE 3/4" INLET PORTS

PART NO. 3806

INLET: ¾’’

PRESSURE: 3 - 16 BAR

MAX. COMPRESSOR CAPACITY 500 M³/MIN. (17500 CFM)

Pneumatically operated condensate drain

The NUFORS-XF removes all types of condensate from large capacity compressed air applications up to 500 m³/min, without using electricity and without the unnecessary loss of compressed air. The NUFORS-XF has an exceptional large condensate discharge capacity of 4.800 litres per hour at 16 bar.

The discharge process is automatic and is based on a 3/2 way level controlled valve principle that operates a piston type direct acting valve.

The NUFORS-XF is ideally suited in applications where power is not available, too expensive or not reliable. The NUFORS-XF features a specially treated robust aluminium housing suitable for oil lubricated and oil-free applications.

In addition, the NUFORS-XF can be applied in applications that demand a higher enclosure protection rating. The NUFORS-XF offers an IP68/NEMA6 rating.

Specifications

MAX. COMPRESSOR CAPACITY 500 m³/min. (17500 CFM) guideline only

MAX. DRAINAGE CAPACITY 4800 litres condensate per hour at 16 bar

MIN./MAX. SYSTEM PRESSURE 3 - 16 bar (44 - 230 psi)

MIN./MAX. MEDIUM TEMPERATURE 1 - 50 °C (34 - 122 °F)

MIN./MAX. AMBIENT TEMPERATURE 1 - 50 °C (34 - 122 °F)

ENCLOSURE PROTECTION RATING IP68 (NEMA6)

INLET CONNECTION 3/4" BSP or NPT, 3 inlet options

INLET HEIGHT 15.1 cm (top), 13.3 cm and 1.8 cm (side)

OUTLET CONNECTION 3/4" BSP, with brass hose barb adapter

VALVE TYPE Direct acting

VALVE ORIFICE 12 mm

VALVE SEALS FPM SERVICEABLE VALVE Yes

HOUSING MATERIAL Corrosion resistant aluminium, EP coating

TEST FEATURE Yes
