MÁY SẤY KHÍ DESICCANT, MODEL SXD-200

Rated volume

1 - 200m3/min

Pressure drop

≤ 0.021Mpa

Inlet pressure

0.45 - 1.0Mpa( rated 0.7Mpa)

Regeneration mode

Normal temperature regeneration

Inlet temperature

≤ 40 ℃ ( rated 38 ℃，saturated )

Working mode

Two tower 4min or 10min automatically switching, continuous work

Inlet oil content

≦ 0.08ppm(0.1mg/m3)

Control mode

Cycle 4-10min  may adjustment

Gas containing dust

≤ 60μm

Installation

Indoor

Average regenerated flow

10 ﹪ - 22 ﹪rated treatment capacity

power

220V/50Hz /1PH

Adsorbent

Active alumina （ Higher requirements with molecular sieves ）

Pressure dew point

-20~-40 ℃ （molecular sieves -70 ℃ accessible）

Model

Rated processing capacity  Nm3/min

dimension
L*W*H mm

Inlet and outlet pipe size

Adsorbent filling amount

KG

Muffler interface

Net weight

KG

SXD-001

1.2

825*460*1152

Rc1

25

1/2”

105

SXD-002

2.4

825*460*1152

Rc1

50

1/2“

135

SXD-003

3.2

825*460*1502

Rc1

75

1”

187

SXD-004

5.0

825*460*1952

Rc1-1/2

125

1“

238

SXD-007

8.5

930*490*1780

Rc1-1/2

175

1”

292

SXD-010

11

1030*580*2230

Rc2

250

1.5“

466

SXD-013

13.5

1030*580*2030

Rc2

300

1.5”

650

SXD-015

17

1220*650*2030

PN1.0 DN65 Flange

365

1.5“

720

SXD-020

23

1220*650*2238

PN1.0 DN80 Flange

450

2”

798

SXD-025

27

1220*650*2740

PN1.0 DN80 Flange

575

2“

955

SXD-030

33

1450*1400*2740

PN1.0 DN80 Flange

690

2”

1278

SXD-040

42

1650*1400*2850

PN1.0 DN100 Flange

920

DN65

1624

SXD-050

55

1850*1600*3020

PN1.0 DN100 Flange

1150

DN65

2242

SXD-060

65

1950*1800*3106

PN1.0 DN100Flange

1380

DN65

2652

SXD-080

85

2420*1200*3253

PN1.0 DN125Flange

1850

DN80

3518

SXD-100

110

2700*1290*3414

PN1.0 DN125 Flange

2500

DN80

4584

SXD-150

165

2860*1390*3464

PN1.0 DN150 Flange

3500

DN100

5231

SXD-200

220

3570*1650*3728

PN1.0 DN200Flange

4600

DN100

8489
